HIGHSIDER 204-345 : HIGHSIDER Rocket Classic 2in1 LED Indicator/Position Light

HIGHSIDER Rocket Classic LED turn signal / position light with aluminium housing and tinted glass.

The striking variant to the model HIGHSIDER Rocket Bullet

In the center are 6 very bright SMD installed. The outer ring consists of COBs (Chip On Board). Thanks to the new LED chip embedding for high-power LEDs, a very high luminance can be achieved with currently the best possible efficiency and service life. This also allows higher light values to be achieved than with conventional LEDs.

Dimensions

• A Diameter: 45 mm


• B Width: 67 mm


• C Depth: 70 mm


• Pole length: 24 mm


• Fixing bolt with M8 thread, length: 25 mm.

Connections:

• Black = Ground (-)


• Yellow = Turn signal (+)


• White = Position light (+)

Scope of supply: 1 pair
